T2 Bay Master Parts Catalogue
1968–1979
Section 01 — Engine. 22 pages, lifted straight out of the book. Not a preview, not a sample spread — the whole section, as printed.
Engine is the big one — block, head, timing gear, pistons, bearings and gaskets, laid out exactly as the factory drew them.
Every diagram is the factory drawing, and every numbered position on it has the VW part number and description printed alongside. It is the same reference the trade uses, set out so you can find a part without knowing what it is called first.
Where shall we send it?
Enter your email and the chapter opens on the next screen.
Your chapter is ready.
Open the engine chapter (PDF, 24pp)Save it to your phone while you have it open.
The rest of the book
That was one section of 360 pages. The full Type 2 Bay Window Master Parts Catalogue carries 139 diagrams and [object Object] part numbers — every section, in workshop order.
See the full catalogue — from £34.95
