Which VW part numbers are on the accelerator pedalaccelerator cable manual gearbox diagram for the Mk1 Golf?

This diagram lists 26 OEM part numbers for the Mk1 Golf. The first three are 443 721 543, 172 721 509 B and 171 721 555 AB.

Which Mk1 Golf years and engines does this diagram cover?

This plate is from the Mk1 Golf 1982 - 1983 generation (RDW). The factory catalogue records no engine-code restriction on it, so it applies to all engines listed in the factory catalogue for this generation.

Where is the complete Mk1 Golf factory parts catalogue?

The Mk1 Golf Master Parts Catalogue is available in print and as a PDF from Type 19 Specialists at /shop/library/catalogue-mk1-hatch-full/. It carries every plate in this catalogue, not just this one.

Accelerator pedalaccelerator cable manual gearbox — Mk1 Golf Pedals (1982 - 1983)

Factory title: Volkswagen Golf (1982 - 1984) - Brake, clutch pedal cluster, clutch cable

Generation: Mk1 1982 - 1983 (RDW) Group: Pedals Parts: 27 Primary OEM: 443 721 543, 172 721 509 B, 171 721 555 AB

Accelerator pedalaccelerator cable manual gearbox for the Volkswagen Golf Mk1 (1982 - 1983): factory exploded diagram 129000 from the Volkswagen ETKA parts catalogue, group 04 Pedals, listing 26 OEM part numbers across 27 catalogued positions including 443 721 543, 172 721 509 B and 171 721 555 AB. Published by Type 19 Specialists; the complete Mk1 Golf catalogue is in print as the Mk1 Golf Master Parts Catalogue.

Parts on this diagram

This Mk1 Golf plate lists 26 OEM part numbers across 27 numbered positions.

Exploded view from the factory parts catalogue. Click a row in the parts table to highlight its position on this diagram. Click any position on the diagram to scroll to its row.

№	Description	Part number
	Accelerator pedalaccelerator cable manualgearbox	—
-	Stop buffer	443 721 543
(1)	Accelerator pedal with weldedon mounting for attachment	172 721 509 B
(11)	accelerator cablepink mark F 15-D-000 001>>F 16-D-051 627>>F 17-D-051 627>>F 53-D-000 001>> 1146 MM K-JETRONICK-JETRONICK-JETRONICK-JETRONIC 1146 MM	171 721 555 AB
(11)	accelerator cablepink mark F >> 15-C-050 000 F >> 16-D-051 626 F >> 17-D-051 626 F >> 53-C-100 000 1146 MM K-JETRONICK-JETRONICK-JETRONICK-JETRONIC 1146 MM	171 721 555 K
(11)	accelerator cablemarked green 1167 MM DIESEL,T-DIESEL 1167 MM	172 721 555 G
1	Accelerator pedal with weldedon mounting for attachment	171 721 509 D
11	accelerator cable 914 MM DIESEL,T-DIESEL 914 MM	357 721 555 A
12	abutment "S..","CH.":keihincarburetor	049 103 775 A
13	Hexagon bolt M 8 X 12 M 8 X 12	N 010 237 6
14	abutment	049 129 239 E
15	Hexagon bolt M 6 X 15 M 6 X 15	N 010 215 13
15	Hexagon bolt M 6 X 15 M 6 X 15	N 010 215 27
16	Rubber bush	431 721 559
17	Clip carburetorengine	046 129 559
18	Retaining washer 8 carburetorengine 8	N 012 328 1
19	securing clip K-JETRONIC;DIESEL	171 721 570 A
2	Clamping washer 8 8	N 012 858 2
20	Stop buffer	171 723 589 A
22	Clip	321 711 537
23	Cable ties 4,6 X 200 4,6 X 200	N 906 661 01
23	Clip	867 971 848
3	Spring washer 8 8	N 900 020 01
5	Stop for accelerator pedal	823 721 527
6	Rosette	171 723 528
7	Bearing bush	823 721 543
8	accelerator cable 1068 MM carburetorengine 1068 MM	171 721 555 T

From the Type 19 workshop

Volkswagen Golf Mk1 work in the Type 19 workshop — the same cars these pedals diagrams are drawn from.

Wait for it…Mk2 Gti 16v Drivetrain and engine Rebuild! #mk2golf #16v #classicparts Mk2 GTI 16v drivetrain and engine rebuild in the Type 19 workshop.

Fitment and applicability

What this plate covers, as the factory catalogue records it — nothing here is inferred from the part names.

Vehicle: Volkswagen Golf Mk1
Model years: 1982 - 1983
Generation region: RDW
Generation code: 007
Factory group: 04 Pedals
Factory subgroup: 129000
