Parking aid — Mk4 Golf Fuel Supply (2003 - 2004)
Factory title: Volkswagen Golf/Golf R32 (2003 - 2006) - Parking aid
Parking aid for the Volkswagen Golf Mk4 (2003 - 2004): factory exploded diagram 919030 from the Volkswagen ETKA parts catalogue, group 29 Fuel / air power supply, listing 19 OEM part numbers including 1J0 919 087 G, 1J0 919 087 J and 1J0 919 051 K. Parts on this plate carry the engine codes BAD, BFH and BHR. Published by Type 19 Specialists; the complete Mk4 Golf catalogue is in print as the Mk4 Golf Master Parts Catalogue.
Parts on this diagram
This Mk4 Golf plate lists 19 OEM part numbers across 19 numbered positions.
| № | Description | Part number |
|---|---|---|
| (1) | Fuel delivery modulecontains additional positions: 3 BAR VDO 4 4 Motion+Petr. engine 3 BAR VDO 4 | 1J0 919 087 G |
| (1) | Fuel delivery module 3,0 BAR VDO Frt.-wh.dr.+Petr. engine 3,0 BAR VDO | 1J0 919 087 J |
| (3) | Fuel delivery unitand sender forfuel gauge Frt.-wh.dr.+BAD BAD | 1J0 919 051 K |
| (3) | Fuel delivery unitand sender forfuel gauge 4 Motion+PR:0 F 9 | 1J0 919 050 A |
| (3) | Fuel delivery unitand sender forfuel gauge PIERBURG Frt.-wh.dr.+PR:0 F 9 PIERBURG | 1J0 919 050 B |
| (3) | Fuel delivery unitand sender forfuel gauge VDO 4 Motion+BFH,BHR VDO BFHBHR | 8L9 919 051 G |
| (3) | Fuel delivery unitand sender forfuel gauge VDO Frt.-wh.dr.+PR:0 F 9 VDO | 1J0 919 050 |
| (3) | Transmitter unit for fuelgauge Fuel pump VDO 4 Motion+PR:0 F 3 VDO | 1J0 919 183 E |
| (4) | Sender forfuel gauge VDO fr.wheel drv VDO | 8L0 919 673 E |
| (4) | Sender forfuel gauge VDO 4 motion VDO | 1J0 919 673 K |
| (4) | Sender forfuel gauge PIERBURG fr.wheel drv PIERBURG | 1J0 919 673 R |
| (4) | Sender forfuel gauge 4 Motion+BFH,BHR BFHBHR | 8L9 919 673 K |
| (5) | Suction jet pump with sensorfor fuel display 4 Motion+BFH,BHR BFHBHR | 8L9 919 673 J |
| (5) | Suction jet pump with sensorfor fuel display VDO 4 Motion+PR:0 F 3 VDO | 1J0 919 673 M |
| (5) | Suction jet pump with sensorfor fuel display VDO 4 Motion+Petr. engine VDO | 1J0 919 673 P |
| (5) | Suction jet pump with sensorfor fuel display VDO 4 Motion+PR:0 F 9 VDO | 1J0 919 673 Q |
| 2 | seal ring Petrol eng.+4 motion Petrol eng.+fr.wheel drv | 1J0 919 133 A |
| 2 | seal ring Diesel eng.+4 motion Diesel eng.+fr.wheel drv | 1J0 919 133 |
| 3 | Transmitter unit for fuelgauge Frt.-wh.dr.+PR:0 F 3,0 F 8 | 1J0 919 183 D |
From the Type 19 workshop
Volkswagen Golf Mk4 work in the Type 19 workshop — the same cars these fuel supply diagrams are drawn from.
Fitment and applicability
What this plate covers, as the factory catalogue records it — nothing here is inferred from the part names.
- Vehicle
- Volkswagen Golf Mk4
- Model years
- 2003 - 2004
- Generation region
- MEX, RDW
- Generation code
- 405
- Engine codes on this plate
- BAD, BFH, BHR
- Factory group
- 29 Fuel / air power supply
- Factory subgroup
- 919030
