2001 repair kit for toothed belt with tensioning roller — Mk4 Golf Engine (1998)
Factory title: Volkswagen Golf/Golf R32 (1998 - 2001) - Repair kit for toothed belt with tensioning roller
2001 repair kit for toothed belt with tensioning roller for the Volkswagen Golf Mk4 (1998): factory exploded diagram 109032 from the Volkswagen ETKA parts catalogue, group 01 Engine, listing 30 OEM part numbers across 31 catalogued positions including 038 103 673 B G LB, 038 130 335 A and 038 109 101 R. Parts on this plate carry the engine codes AJM, ARL, ASZ, ATD and AUY. Published by Type 19 Specialists; the complete Mk4 Golf catalogue is in print as the Mk4 Golf Master Parts Catalogue.
Parts on this diagram
This Mk4 Golf plate lists 30 OEM part numbers across 31 numbered positions.
| № | Description | Part number |
|---|---|---|
| camshaft, valves 1.9 ltr. Diesel eng.+ATD,AJM,AUY,ASZ,ARL 1.9 ltr. ATDAJMAUYASZARL | — | |
| yellow | 038 103 673 B G LB | |
| - | Ball pin | 038 130 335 A |
| - | Ball pin | 038 130 335 A |
| 1 | Camshaft | 038 109 101 R |
| 10 | Valve spring | 038 109 623 F |
| 11 | Valve spring | 038 109 633 |
| 12 | spring disc | 021 109 641 C |
| 13 | cotter, split | 021 109 651 |
| 14 | Valve stem seal | 027 109 675 |
| 15 | valve lever shaft | 038 109 401 D |
| 16 | Rocker arm | 038 109 441 C |
| 17 | thrust washer 34,4 X 2 34,4 X 2 | 038 109 422 |
| 18 | Securing ring 30 X 1,5 30 X 1,5 | N 023 644 1 |
| 19 | Locating bolt M 8 X 90 M 8 X 90 | 038 103 714 A |
| 2 | camshaft bearing shell | 038 103 673 B |
| 2 | camshaft bearing shell | 038 103 673 A |
| 20 | adjusting screw with ball-head also use: M 12 X 1,25 X 26,75038 130 335 A M 12 X 1,25 X 26,75038 130 335 A | WHT 000 530 |
| 20 | adjusting screw M 12 X 1,25 X 26 M 12 X 1,25 X 26 | 038 109 451 |
| 21 | Hexagon nut M 12 X 1,25 M 12 X 1,25 | N 104 129 01 |
| 22 | rocker arm shaft withrocker arm also use: 038 130 335 A 038 130 335 A | 038 109 527 AF |
| 22 | rocker arm shaft withrocker arm | 038 109 527 D |
| 3 | toothed belt pulley | 038 109 111 E |
| 4 | hub | 038 109 239 |
| 5 | Hex collared bolt M 8 X 30 M 8 X 30 | N 101 092 10 |
| 6 | hexagon head bolt (combi) M 12 X 1,5 X 35 M 12 X 1,5 X 35 | N 905 021 02 |
| 6 | hexagon head bolt (combi) M 12 X 1,5 X 35 M 12 X 1,5 X 35 | N 905 021 03 |
| 7 | Tappets 35 35 | 038 109 309 A |
| 8 | Inlet valve 90 90 | 038 109 601 B |
| 9 | exhaust valve 89,5 89,5 | 038 109 611 F |
| 9 | exhaust valve 90 90 | 038 109 611 B |
From the Type 19 workshop
Volkswagen Golf Mk4 work in the Type 19 workshop — the same cars these engine diagrams are drawn from.
Fitment and applicability
What this plate covers, as the factory catalogue records it — nothing here is inferred from the part names.
- Vehicle
- Volkswagen Golf Mk4
- Model years
- 1998
- Generation region
- RDW
- Generation code
- 203
- Engine codes on this plate
- AJM, ARL, ASZ, ATD, AUY
- Factory group
- 01 Engine
- Factory subgroup
- 109032
