2001 repair kit for toothed belt with tensioning roller — Mk4 Golf Engine (1998)

Factory title: Volkswagen Golf/Golf R32 (1998 - 2001) - Repair kit for toothed belt with tensioning roller

Generation: Mk4 1998 (RDW) Group: Engine Rebuild step 1 Parts: 14 Primary OEM: 071 109 101 B, 021 109 633 B, 027 109 675

2001 repair kit for toothed belt with tensioning roller for the Volkswagen Golf Mk4 (1998): factory exploded diagram 109035 from the Volkswagen ETKA parts catalogue, group 01 Engine, listing 13 OEM part numbers across 14 catalogued positions including 071 109 101 B, 021 109 633 B and 027 109 675. Parts on this plate carry the engine code AGZ. Published by Type 19 Specialists; the complete Mk4 Golf catalogue is in print as the Mk4 Golf Master Parts Catalogue.

Parts on this diagram

This Mk4 Golf plate lists 13 OEM part numbers across 14 numbered positions.

Exploded view from the factory parts catalogue. Click a row in the parts table to highlight its position on this diagram. Click any position on the diagram to scroll to its row.

№	Description	Part number
	camshaft, valves 2.3 ltr. 5-cylinder+AGZ 2.3 ltr. AGZ	—
1	Camshaft	071 109 101 B
10	Valve spring	021 109 633 B
11	Valve stem seal	027 109 675
12	Inlet valve 105,95 105,95	021 109 601 L
13	exhaust valve 106,95 106,95	021 109 611 G
2	Camshaft	071 109 102 A
3	Chain sprocket Z=27 Z=27	021 109 111 H
4	Position sensor wheel forcamshaft	071 109 227
5	Hexagon bolt M 12 X 1,5 X 40 M 12 X 1,5 X 40	N 102 038 03
6	Tappets	034 109 309 AD
7	cotter, split	021 109 651
8	spring disc	021 109 641 C
9	Valve spring	021 109 623 P

From the Type 19 workshop

Volkswagen Golf Mk4 work in the Type 19 workshop — the same cars these engine diagrams are drawn from.

Volkswagen OEM Parts Catalogues and Torque reference manuals! Get amongst it. Volkswagen OEM Parts Catalogues and Torque reference manuals from Type 19 Specialists — the printed editions the free catalogue pages are drawn from.

Fitment and applicability

What this plate covers, as the factory catalogue records it — nothing here is inferred from the part names.

Vehicle: Volkswagen Golf Mk4
Model years: 1998
Generation region: RDW
Generation code: 203
Engine codes on this plate: AGZ
Factory group: 01 Engine
Factory subgroup: 109035
