Which VW part numbers are on the sender fuel gauge diagram for the Mk3 Golf?

This diagram lists 15 OEM part numbers for the Mk3 Golf. The first three are 1H0 919 673 F, 1H0 919 673 H and 1H0 919 651 Q.

Which Mk3 Golf years and engines does this diagram cover?

This plate is from the Mk3 Golf 1994 - 1997 generation (RDW). The parts on it carry the engine codes 2E, AAM and ABS.

Where is the complete Mk3 Golf factory parts catalogue?

The Mk3 Golf Master Parts Catalogue is available in print and as a PDF from Type 19 Specialists at /shop/library/catalogue-mk3-full/. It carries every plate in this catalogue, not just this one.

Sender fuel gauge — Mk3 Golf Dash Panel Centre Console (1994 - 1997)

Factory title: Volkswagen Golf Cabriolet (1994 - 1998) - Distance sensor. Combi-instrument

Generation: Mk3 1994 - 1997 (RDW) Group: Dash panel / centre console Parts: 16 Primary OEM: 1H0 919 673 F, 1H0 919 673 H, 1H0 919 651 Q

Sender fuel gauge for the Volkswagen Golf Mk3 (1994 - 1997): factory exploded diagram 919051 from the Volkswagen ETKA parts catalogue, group 32 Dash panel / centre console, listing 15 OEM part numbers across 16 catalogued positions including 1H0 919 673 F, 1H0 919 673 H and 1H0 919 651 Q. Parts on this plate carry the engine codes 2E, AAM and ABS. Published by Type 19 Specialists; the complete Mk3 Golf catalogue is in print as the Mk3 Golf Master Parts Catalogue.

Parts on this diagram

This Mk3 Golf plate lists 15 OEM part numbers across 16 numbered positions.

Exploded view from the factory parts catalogue. Click a row in the parts table to highlight its position on this diagram. Click any position on the diagram to scroll to its row.

№	Description	Part number
	Sender forfuel gauge diesel eng.	—
(13)	Sender forfuel gauge VDO ABS,AAM,2 E VDO 2EAAMABS	1H0 919 673 F
(13)	Sender forfuel gauge PIERBURG "J..":2 E PIERBURG	1H0 919 673 H
(8)	fuel pump with housing use if required: 4,0 BAR VDO 1 H 0 919 673 F 000 979 105 "J..":2 E 4,0 BAR VDO 1 H 0 919 673 F 000 979 105	1H0 919 651 Q
(8)	fuel pump with housing 1 BAR VDO AAM,ABS 1 BAR VDO AAMABS	1H0 919 651 N
(8)	fuel pump with housing 3 BAR VDO 2 E 3 BAR VDO 2E	1H0 919 651 P
1	Sender forfuel gauge	1H0 919 183
10	Flat contact housing	357 906 231
12	seal ring 109 109	321 919 133
14	flange	1H0 919 679 E
15	clamp 11,9 X 7 X 0,6 11,9 X 7 X 0,6	N 103 100 01
16	Cable ties 3,6 X 246 3,6 X 246	N 020 902 2
2	seal ring	1H0 919 133
2	seal ring	8E0 919 133 E
2	seal ring	1J0 919 133
3	flat contact housing withgasket	357 972 752

From the Type 19 workshop

Volkswagen Golf Mk3 work in the Type 19 workshop — the same cars these dash panel centre console diagrams are drawn from.

Mk2 Golf Restoration Welding work #mk2golf #mechanic #volkswagen #migwelding #carrestoration Mostly typical repair work we see on almost every Mk2 Golf we’ve worked on. Safe to say the Mk3 Golf is pretty similar too!

Fitment and applicability

What this plate covers, as the factory catalogue records it — nothing here is inferred from the part names.

Vehicle: Volkswagen Golf Mk3
Model years: 1994 - 1997
Generation region: RDW
Generation code: 146
Engine codes on this plate: 2E, AAM, ABS
Variant tags: diesel
Factory group: 32 Dash panel / centre console
Factory subgroup: 919051
