Which VW part numbers are on the three point safety belt front diagram for the Mk3 Golf?

This diagram lists 43 OEM part numbers for the Mk3 Golf. The first three are 1H1 857 755 0 1C, 443 857 847 B 4 PK and 1E0 857 706 B B 41.

Which Mk3 Golf years and engines does this diagram cover?

This plate is from the Mk3 Golf 1994 - 1997 generation (RDW). The factory catalogue records no engine-code restriction on it, so it applies to all engines listed in the factory catalogue for this generation.

Where is the complete Mk3 Golf factory parts catalogue?

The Mk3 Golf Master Parts Catalogue is available in print and as a PDF from Type 19 Specialists at /shop/library/catalogue-mk3-full/. It carries every plate in this catalogue, not just this one.

Three point safety belt front — Mk3 Golf Dash Panel Centre Console (1994 - 1997)

Factory title: Volkswagen Golf Cabriolet (1994 - 1998) - Dashboard. dashboard fittings

Generation: Mk3 1994 - 1997 (RDW) Group: Dash panel / centre console Parts: 43 Primary OEM: 1H1 857 755 0 1C, 443 857 847 B 4 PK, 1E0 857 706 B B 41

Three point safety belt front for the Volkswagen Golf Mk3 (1994 - 1997): factory exploded diagram 857060 from the Volkswagen ETKA parts catalogue, group 32 Dash panel / centre console, listing 43 OEM part numbers including 1H1 857 755 0 1C, 443 857 847 B 4 PK and 1E0 857 706 B B 41. Published by Type 19 Specialists; the complete Mk3 Golf catalogue is in print as the Mk3 Golf Master Parts Catalogue.

Parts on this diagram

This Mk3 Golf plate lists 43 OEM part numbers across 43 numbered positions.

Exploded view from the factory parts catalogue. Click a row in the parts table to highlight its position on this diagram. Click any position on the diagram to scroll to its row.

№	Description	Part number
	Satin black	1H1 857 755 0 1C
	soul (black)	443 857 847 B 4 PK
	Satin black	1E0 857 706 B B 41
	Satin black	1H2 857 756 A 0 1C
	Satin black	1HM 857 756 0 1C
	Satin black	6N0 857 719 B 41
	Satin black	1E0 857 705 B 41
	Satin black	1H0 857 756 0 1C
	Satin black	1H0 857 755 0 1C
	Satin black	1E0 857 705 A B 41
	Satin black	1E0 857 705 D B 41
-	Mount.block for belt tensioner	1H0 858 891
(1)	Three-point safety belt(passenger side)	1E0 857 705
(11)	guide arm F >> 1 E-R-012 000*	1H0 857 825
(11B)	Clamp F >> 1 E-R-012 000*	1H0 804 317
(12)	guide arm F 1 E-R-012 001>>*	1H0 857 825 A
(13)	Washer 11,5 X 21 X 1,8 11,5 X 21 X 1,8	N 011 655 2
(2)	three-point automatic seatbelt with belt tensioner*** Caution Hazardous ****	1E0 857 705 D
(20)	Belt latchfor:three-point automatic seatbelt with belt tensioner F 1 E-S-001 541>>	1HM 857 756
(20)	Belt latch with warningcontact	1H2 857 756 A
(20)	Belt latch	1H0 857 755
(20)	Belt latch with warningcontact	1H1 857 755
1	three-point seat belt withtravel limiter	1E0 857 705 A
11	guide arm F >> 1 E-R-012 000*	1H0 857 826
11A	rubber ring	171 823 481 A
11B	Clamp F >> 1 E-R-012 000*	1H0 804 318
12	guide arm F 1 E-R-012 001>>*	1H0 857 826 A
13	Cover cap	1H0 857 741 A
14	Hexagon bolt 7/16"X 25 7/16"X 25	111 857 799
14B	Socket head bolt withhexagon socket head F 1 E-R-012 001>>* M 8 X 20 M 8 X 20	N 014 779 1
16	Seat belt height adjuster	6N0 857 819
17	Socket head bolt withhexagon socket head M 8 X 20 M 8 X 20	N 014 779 1
2	three-point automatic seatbelt with belt tensioner*** Caution Hazardous ****	1E0 857 706 B
20	Belt latch	1H0 857 756
21	Hexagon bolt 7/16"X 20 7/16"X 20	111 857 799 A
21	Hexagon bolt 7/16"X 20 7/16"X 20	3B0 857 799
23	knob	443 857 847 B
23	knob 16 MM 16 MM	443 857 847 B
3	fitted bolt, hexagon head 7/16"-20 UNFX 39 7/16"-20 UNFX 39	N 989 903 01
4	Hexagon bolt 7/16"X 25 7/16"X 25	111 857 799
6	Cover cap	6N0 857 719
8	Seat belt guide	1E0 857 817 A
9	oval head panel screw 4,8 X 13 4,8 X 13	N 013 968 1

From the Type 19 workshop

Volkswagen Golf Mk3 work in the Type 19 workshop — the same cars these dash panel centre console diagrams are drawn from.

Mk2 Golf Restoration Welding work #mk2golf #mechanic #volkswagen #migwelding #carrestoration Mostly typical repair work we see on almost every Mk2 Golf we’ve worked on. Safe to say the Mk3 Golf is pretty similar too!

Fitment and applicability

What this plate covers, as the factory catalogue records it — nothing here is inferred from the part names.

Vehicle: Volkswagen Golf Mk3
Model years: 1994 - 1997
Generation region: RDW
Generation code: 146
Factory group: 32 Dash panel / centre console
Factory subgroup: 857060
