Which VW part numbers are on the three point safety belt lap belt rear diagram for the Mk3 Golf?

This diagram lists 49 OEM part numbers for the Mk3 Golf. The first three are 1H4 857 806 A 6 NS, 443 857 847 B 4 PK and 1H0 857 713 A F ES.

Which Mk3 Golf years and engines does this diagram cover?

This plate is from the Mk3 Golf 1997 generation (RDW). The factory catalogue records no engine-code restriction on it, so it applies to all engines listed in the factory catalogue for this generation.

Where is the complete Mk3 Golf factory parts catalogue?

The Mk3 Golf Master Parts Catalogue is available in print and as a PDF from Type 19 Specialists at /shop/library/catalogue-mk3-full/. It carries every plate in this catalogue, not just this one.

Three point safety belt lap belt rear — Mk3 Golf Dash Panel Centre Console (1997)

Factory title: Volkswagen Golf (1997 - 1998) - Dashboard. dashboard fittings

Generation: Mk3 1997 (RDW) Group: Dash panel / centre console Parts: 51 Primary OEM: 1H4 857 806 A 6 NS, 443 857 847 B 4 PK, 1H0 857 713 A F ES

Three point safety belt lap belt rear for the Volkswagen Golf Mk3 (1997): factory exploded diagram 857070 from the Volkswagen ETKA parts catalogue, group 32 Dash panel / centre console, listing 49 OEM part numbers across 51 catalogued positions including 1H4 857 806 A 6 NS, 443 857 847 B 4 PK and 1H0 857 713 A F ES. Published by Type 19 Specialists; the complete Mk3 Golf catalogue is in print as the Mk3 Golf Master Parts Catalogue.

Parts on this diagram

This Mk3 Golf plate lists 49 OEM part numbers across 51 numbered positions.

Exploded view from the factory parts catalogue. Click a row in the parts table to highlight its position on this diagram. Click any position on the diagram to scroll to its row.

№	Description	Part number
	bright red -35 -35	1H4 857 806 A 6 NS
	soul (black)	443 857 847 B 4 PK
	flash red -35 GTI -35	1H0 857 713 A F ES
	Satin black	1H0 857 713 A 0 1C
	bright red -35 -35	1H0 857 713 A 6 NS
	Satin black	1H3 858 884 B 41
	Satin black	1H0 857 739 A 0 1C
	satin black/fire red -35 GTI -35	1H0 857 739 A F CN
	bright red -35 -35	1H3 857 805 A 6 NS
	flash red -35 -35	1H3 857 805 A 1 NQ
	Satin black	1H3 857 806 A B 41
	bright red -35 -35	1H3 857 806 A 6 NS
	flash red -35 -35	1H3 857 806 A 1 NQ
	Satin black	1H4 857 805 A B 41
	flash red -35 -35	1H4 857 805 A 1 NQ
	Satin black	1H2 857 806 A B 41
	bright red -35 -35	1H4 857 805 A 6 NS
	Satin black	1H4 857 806 A B 41
	flash red -35 -35	1H4 857 806 A 1 NQ
	satin black/fire red	1E0 857 739 F CN
	satin black/fire red	1E0 857 740 F CN
	Satin black	1H3 858 883 B 41
	Satin black	1H3 857 805 A B 41
-	Belt latch	1E0 857 739
-	Belt latch	1E0 857 740
(16)	Socket head bolt withhexagon socket head M 8 X 20 M 8 X 20	N 014 779 1
(20)	Retainer for safety belt	1H3 858 884
(6)	Three-point safety belt	1H3 857 805 A
(6)	Three-point safety belt	1H3 857 806 A
(8)	Three-point safety belt	1H4 857 805 A
(8)	Three-point safety belt	1H4 857 806 A
(8)	Three-point safety belt "AUS"	1H2 857 806 A
(8)	Three-point safety belt	1H4 857 806 A
(8)	Three-point safety belt	1H4 857 805 A
1	Lap belt with beltlock	1H0 857 713 A
1	Lap belt with beltlock	1H0 857 713 A
10	knob	443 857 847 B
11	Hexagon bolt 7/16"X 25 7/16"X 25	111 857 799
12	Shim 11,2 X 17 X 8,5 11,2 X 17 X 8,5	810 019 829
13	Hexagon bolt	111 857 793 E
15	seat belt heightadjuster	1H0 857 819
16	Socket head bolt withhexagon socket head M 8 X 16 M 8 X 16	N 014 739 2
17	Locating bolt 7/16"X 22 7/16"X 22	1H0 857 846
2	Double belt latch	1H0 857 739 A
20	Retainer for safety belt	1H3 858 883
21	nut,thread cutting 5 5	N 038 601 1
3	Cover cap	1H0 857 741
30	see illustration: 867-065 867-065	—
31	see illustration: 867-065 867-065	—
4	Washer 11,5 X 21 X 1,8 11,5 X 21 X 1,8	N 011 655 2
5	Hexagon bolt 7/16"X 25 7/16"X 25	111 857 799

From the Type 19 workshop

Volkswagen Golf Mk3 work in the Type 19 workshop — the same cars these dash panel centre console diagrams are drawn from.

Mk2 Golf Restoration Welding work #mk2golf #mechanic #volkswagen #migwelding #carrestoration Mostly typical repair work we see on almost every Mk2 Golf we’ve worked on. Safe to say the Mk3 Golf is pretty similar too!

Fitment and applicability

What this plate covers, as the factory catalogue records it — nothing here is inferred from the part names.

Vehicle: Volkswagen Golf Mk3
Model years: 1997
Generation region: RDW
Generation code: 184
Factory group: 32 Dash panel / centre console
Factory subgroup: 857070
