Which VW part numbers are on the protective stripsmolding roof diagram for the Mk3 Golf?

This diagram lists 85 OEM part numbers for the Mk3 Golf. The first three are 1H6 853 706 C B 41, 1H0 853 518 B G RU and 1H3 853 535 B 41.

Which Mk3 Golf years and engines does this diagram cover?

This plate is from the Mk3 Golf 1997 generation (RDW). The factory catalogue records no engine-code restriction on it, so it applies to all engines listed in the factory catalogue for this generation.

Where is the complete Mk3 Golf factory parts catalogue?

The Mk3 Golf Master Parts Catalogue is available in print and as a PDF from Type 19 Specialists at /shop/library/catalogue-mk3-full/. It carries every plate in this catalogue, not just this one.

Protective stripsmolding roof — Mk3 Golf Front Body (1997)

Factory title: Volkswagen Golf (1997 - 1998) - Molding - roof. Protective strips

Generation: Mk3 1997 (RDW) Group: Front body Parts: 85 Primary OEM: 1H6 853 706 C B 41, 1H0 853 518 B G RU, 1H3 853 535 B 41

Protective stripsmolding roof for the Volkswagen Golf Mk3 (1997): factory exploded diagram 853000 from the Volkswagen ETKA parts catalogue, group 25 Front body, listing 85 OEM part numbers including 1H6 853 706 C B 41, 1H0 853 518 B G RU and 1H3 853 535 B 41. Published by Type 19 Specialists; the complete Mk3 Golf catalogue is in print as the Mk3 Golf Master Parts Catalogue.

Parts on this diagram

This Mk3 Golf plate lists 85 OEM part numbers across 85 numbered positions.

Exploded view from the factory parts catalogue. Click a row in the parts table to highlight its position on this diagram. Click any position on the diagram to scroll to its row.

№	Description	Part number
	Satin black	1H6 853 706 C B 41
	primed	1H0 853 518 B G RU
	Satin black	1H3 853 535 B 41
	primed	1H0 853 518 C G RU
	Satin black	1H4 853 754 B 41
	primed	1H3 853 515 C G RU
	primed	1H4 853 753 C G RU
	Satin black	1H3 853 515 A B 41
	primed	1H4 853 536 C G RU
	Satin black	1H3 853 516 B 41
	Satin black	1H4 853 753 B 41
	primed	1H3 853 516 C G RU
	Satin black	1H4 853 753 A B 41
	Satin black	1H3 853 516 A B 41
	Satin black	1H6 853 706 B B 41
	Satin black	1H4 853 536 B 41
	Satin black	1H6 853 705 C B 41
	Satin black	1H4 853 515 B 41
	primed	1H4 853 535 C G RU
	primed	1H4 853 515 C G RU
	Satin black	1H4 853 535 B 41
	Satin black	1H4 853 515 A B 41
	Satin black	1H3 853 536 A B 41
	Satin black	1H4 853 516 B 41
	primed	1H4 853 754 C G RU
	primed	1H4 853 516 C G RU
	primed	1H3 853 536 C G RU
	Satin black	1H4 853 516 A B 41
	Satin black	1H3 853 536 B 41
	Satin black	1H6 853 705 B B 41
	Satin black	1H4 853 754 A B 41
	Satin black	1H0 853 517 B 41
	Satin black	1H3 853 515 B 41
	primed	1H0 853 517 B G RU
	Satin black	1H3 853 535 A B 41
	primed	1H0 853 517 C G RU
	primed	1H3 853 535 C G RU
	Satin black	1H0 853 518 B 41
(1)	Protective strip for door 53 MM 53 MM	1H3 853 516
(1)	Protective strip for door 63 MM 63 MM	1H3 853 515 A
(1)	Protective strip for door 53 MM 53 MM	1H3 853 516 C
(1)	Protective strip for door 63 MM 63 MM	1H3 853 516 A
(1)	Protective strip for door 53 MM 53 MM	1H3 853 515 C
(11)	Protective strip for side sect 53 MM 53 MM	1H4 853 536 C
(11)	Protective strip for side sect 53 MM 53 MM	1H4 853 536
(11)	Protective strip for side sect 53 MM 53 MM	1H4 853 535 C
(12)	Protective strip for door 53 MM 53 MM	1H4 853 754 C
(12)	Protective strip for door 53 MM 53 MM	1H4 853 753 C
(12)	Protective strip for door 63 MM 63 MM	1H4 853 753 A
(12)	Protective strip for door 63 MM 63 MM	1H4 853 754 A
(12)	Protective strip for door 53 MM 53 MM	1H4 853 754
(20)	molding - roof	1H6 853 706 C
(20)	molding - roof	1H6 853 705 C
(20)	molding - roof	1H6 853 706 B
(4)	Protective strip for door 53 MM 53 MM	1H4 853 516
(4)	Protective strip for door 63 MM 63 MM	1H4 853 516 A
(4)	Protective strip for door 53 MM 53 MM	1H4 853 516 C
(4)	Protective strip for door 63 MM 63 MM	1H4 853 515 A
(4)	Protective strip for door 53 MM 53 MM	1H4 853 515 C
(7)	Protective strip for wings 53 MM 53 MM	1H0 853 518 C
(7)	Protective strip for wings 53 MM 53 MM	1H0 853 517 B
(7)	Protective strip for wings 53 MM 53 MM	1H0 853 517 C
(7)	Protective strip for wings 53 MM 53 MM	1H0 853 518
(7)	Protective strip for wings 53 MM 53 MM	1H0 853 518 B
(8)	Protective strip for side sect 63 MM 63 MM	1H3 853 536 A
(8)	Protective strip for side sect 53 MM 53 MM	1H3 853 535 C
(8)	Protective strip for side sect 63 MM 63 MM	1H3 853 535 A
(8)	Protective strip for side sect 53 MM 53 MM	1H3 853 536
(8)	Protective strip for side sect 53 MM 53 MM	1H3 853 536 C
1	Protective strip for door 53 MM 53 MM	1H3 853 515
10	Clip	1H0 853 585 A
11	Protective strip for side sect 53 MM 53 MM	1H4 853 535
12	Protective strip for door 53 MM 53 MM	1H4 853 753
13	Clip	1H0 853 585
14	Grommet	1H0 853 586
2	Clip	1H0 853 585
20	molding - roof	1H6 853 705 B
21	Clip	1H0 853 733 B
3	Clip	1H0 853 585 B
4	Protective strip for door 53 MM 53 MM	1H4 853 515
5	Clip	1H0 853 585
6	Clip	1H0 853 585 B
7	Protective strip for wings 53 MM 53 MM	1H0 853 517
8	Protective strip for side sect 53 MM 53 MM	1H3 853 535
9	Clip	1H0 853 585

From the Type 19 workshop

Volkswagen Golf Mk3 work in the Type 19 workshop — the same cars these front body diagrams are drawn from.

Mk2 Golf Restoration Welding work #mk2golf #mechanic #volkswagen #migwelding #carrestoration Mostly typical repair work we see on almost every Mk2 Golf we’ve worked on. Safe to say the Mk3 Golf is pretty similar too!

Fitment and applicability

What this plate covers, as the factory catalogue records it — nothing here is inferred from the part names.

Vehicle: Volkswagen Golf Mk3
Model years: 1997
Generation region: RDW
Generation code: 184
Factory group: 25 Front body
Factory subgroup: 853000
